Bladder accumulator
Ningbo Chaori Hydraulic Co .,Ltd. is located in National AAAAA scenic resort Xikou town,Fenghua, Ningbo.The company covers an area of 18000 square meters, and has been equipped with perfect manufacturing machines and detecting instruments. lt passed the lSO9001-2000 certification in 2000,and had the important certificates and licenses, including the Special Equipment Designing and Manufacture License issued by General Administration of Quality Supervision ,Inspection and Quarantine, of China，ASME manufacture certificate of pressure vessel ,and EU CE certificate. The company took part in the establishment of accumulator type national standard.
Technical Specifications
| Model | Max. Pressure (Bar) |
Volume (L) |
M | Gas Valve | Connection Type | Ø | Weight (kg) |
|
|---|---|---|---|---|---|---|---|---|
| L2 | L1 | |||||||
| NXQA-*-1.5/*-L(F)-* | 315 | 1.5 | G3/4" | 1/2"-20 UNF 5/8" UNF |
250 | 368 | 114 | 8.5 |
| NXQA-*-2.5/*-L(F)-* | 2.5 | G1 1/4" | 280 | 410 | 152 | 15 | ||
| NXQA-*-4/*-L(F)-* | 4 | 300 | 427 | 168 | 18 | |||
| NXQA-*-6.3/*-L(F)-* | 6.3 | 440 | 567 | 168 | 24 | |||
| NXQA-*-10/*-L(F)-* | 10 | G2" | 410 | 571 | 168 | 41 | ||
| NXQA-*-20/*-L(F)-* | 20 | 725 | 886 | 229 | 62 | |||
| NXQA-*-24/*-L(F)-* | 24 | 870 | 1026 | 229 | 74 | |||
| NXQA-*-30/*-L(F)-* | 30 | 1100 | 1211 | 229 | 82 | |||
| NXQA-*-35/*-L(F)-* | 35 | 1220 | 1376 | 229 | 96 | |||
| NXQA-*-40/*-L(F)-* | 40 | 1340 | 1501 | 229 | 104 | |||
| NXQA-*-50/*-L(F)-* | 50 | 1650 | 1811 | 229 | 118 | |||
